Rims

- To be used exclusively with Bontrager 29""/700c Tubeless Ready (TLR) wheels - TLR Rim Strips are the light and easy solution to Bontrager Tubeless conversion - Rim Strip replacement is recommended if removed from the wheel

- To be used exclusively with Bontrager 29""/700c Tubeless Ready (TLR) wheels - TLR Rim Strips are the light and easy solution to Bontrager Tubeless conversion - Rim Strip replacement is recommended if removed from the wheel

• Original equipment Bontrager AT series rims • Double wall construction • Disc brake compatible • Pinned seam • Presta valve • Aluminum • 32 holes

- Original equipment replacement rims for Bontrager Race Lite wheels - Welded Seam - Presta Valve

PRODUCT SPECS: - Size: 26?, 27.5" (sleeved only), 29? - Outside Width: 27mm - Inner bead width: 22.3mm - Section Height: 20mm - Weight: 26?- 482g, 27.5"-515g, 29?- 547g - Type: Sleeved or Welded - Brake Compatibility: Disc Only - Hole Count: 32

Product specs: - Size:24", 26", 29" - Width:33.5 - Bead width: 33.5mm - Inner bead width: 26mm - Section height: 25.5mm - Weight (26"): 660g - Sleeved or welded - Hole count: 32, 36

PRODUCT SPECS: - Size: 26?, 27.5" (sleeved only) , 29? - Outside Width: 25mm - Inner bead width: 20.3mm - Section Height: 19mm - Weight: 26?- 448g, 27.5"-495g, 29?- 527g - Type: Sleeved or Welded - Brake Compatibility: Disc Only - Hole Count: 28, 32

- Size : 700c - Model : Race - Holes : 24 - ERD : 596mm - Color : Black - Finish : Anodized - Type : Tubeless/Clincher - Valve : Presta - FT/RR/PR : Rear - Rim : Asymmetric - Weight : 465g

Spank's Spoon 32 rims are gravity rims done right! If your rides encompass big hits and fast descents then a pair of Spoon 32 rims might be just what you need to tackle your favored terrain. - Six Series aluminum alloy - Disc specific rim - Tubeless Ready

Product specs: - Size:24", 26" - Width:39mm - Bead width: 39mm - Inner bead width: 30mm - Section height: 27.5mm - Weight (26"): 760g - Sleeved or welded - Hole count: 32, 36

- Original equipment Bontrager Duster rims - Tubeless Ready Design - Optimize with Bontrager TLR Tire Sealant, Tubeless Ready rim strips, valve stems, and tires - Welded seam - Presta valve

PRODUCT SPECS: - Size: 26?, 27.5" (sleeved only) - Outside Width: 31mm - Inner bead width: 25.4mm - Section Height: 22mm - Weight: 26?- 546g 27.5"-589g - Type: Sleeved or Welded - Brake Compatibility: Disc Only - Hole Count: 32

The next step in the Cinema rim line, the 888 is an aero style rim designed for strength and rigidity. The 36mm width fits perfectly with modern sized tires and maximizes strength without adding too much weight. Industry-standard 6061-T6 grade aluminum and a welded seam mean a truly worry-free rim. The uniquely designed rim profile integrates several features for easier tire installation, highly accurately spoke hole drilling for easier wheel builds, and increased wall thickness in the center spoke nipple channel.

Cross riders fear not, your rim is supported. A robust I-Beam pillar runs right down the center of the Frequency CX’s rim cavity. They’re as svelte as they are stiff thanks to WT69 Alloy and with a true TCS profile, tubeless setup is a breeze. So go ahead, build a set and make the rest of the field jealous. Better yet, storm past and force them to keep up. Available in both 32-hole and 28-hole.

Asym rims use an asymmetrical design to create a rim that evenly distributes tension, doesn’t require dishing, and makes for a faster wheel assembly. High end WT69 Alloy and an open cavity design keep Asym weights down while eyelets prolong longevity and prevent binding. Featuring a full TCS (tubeless compatible system) inner rim profile, Asym rims provide a lightweight, higher performance value-driven option that works exceptionally well with wheel building machines.

Wider and even lower in profile, the new Crest MK3 sheds weight for faster acceleration and climbing. WideRight 23mm internal width increases tire volume for improved stability with wider tires. Inspired by carbon technology, the entirely new rim shape adds strength and virtually eliminates the chance of a pinch flat. Refined over the past 15 years, Bead Socket Technology offers the most trusted tubeless seal in the business, making the Crest MK3 the best choice for lightweight, tubeless XC performance. - 23mm internal rim width for more stability with larger tires - Low-profile shape rolls faster, lasts longer, and helps stop tire pinch flats - Laterally stiffer and stronger for improved handling Wider but even lighter than the original Crest - More durable rim shape and alloy Most trusted tubeless system for easy setup and low maintenance - Legendary Crest climbing and speed in a high volume rim - WideRight optimized for XC tires

- Original equipment replacement rim for Bontrager Line wheels - 28mm inner hook bead width - 28 spoke holes - Tubeless ready design - Optimized with Bontrager TLR sealant, TLR rim strips, valves, and tires - Welded seam - Presta valve - Aluminum

- Original equipment replacement rims for Bontrager Race XXX Lite wheels - Aluminum - 29-inch - 28 spoke holes

SPANK’s legendary race rim profile. Spank Industries’ SPIKE Race 28 rim has been a long-time favorite of the gravity fed, from the cliffs of Virgin, Utah, to the steeps of the World Cup. With a trim 22.5mm inner width, the SPIKE Race 28 rounds off tire profiles, reducing rolling resistance and improving maneuverability, for a quicker, more racy feel on track. Bombproof Dynamal alloy construction paired with SPANK’s unique OohBah rim design make the SPIKE Race 28 a go-to hoop for those who demand strength and stiffness in their rims. Now equipped with SPANK’s revolutionary patented Bead Bite tubeless technology, the SPIKE Race 28 rim is a go-to option for riders that require enhanced tubeless security and world class speed and performance. Specs: - Key Technologies :Bead Bite, OohBah, Dynamal Alloy - Material: MGR Dynamal Alloy - Size (in.): 26" / 27.5" - Weight (g): ±480 (26"), ±510 (27.5") - Hole Count: 32H - Inner / Outer Width: 22.5 / 28 - Valve: F/V Presta - Tubeless: Tubeless ready - Finish: Shotpeen anodized, laser logos - ERD (mm++): 528 (26") / 553 (27.5") - ETRTO (mm): 559x22.5 (26") / 584x22.5 (27.5") - Discipline: Race / Freeride

- A high performance alloy rim designed for freeride, race and downhill use - Tubeless ready with anti-burp rim hooks to prevent the loss of pressure and keep tires firmly in place - 32 holes with an inner width of 28mm and outer width of 33mm to optimize tire spread and enhance traction - The corrugated rim center, a brand acclaimed technology, adds exceptional strength, making it more rigid and allowing the rim to be wider without adding material - Shotpeen finish to increase fatigue life and make it more durable

Designed with input from Stan's Enduro World Series teams, the new Arch MK3 is ready to own every trail. WideRight optimized for maximum stability with 2.25-inch to 2.5-inch tires, Stan's expanded the internal width out to 26mm while keeping the rim incredibly light. The 27.5-inch Arch MK3 weighs only 425g. A new proprietary alloy and stronger, low-profile rim shape means the new Arch MK3 is built to last. Featuring Bead Socket Technology, the new Arch MK3 also offers the unmatched traction, control, and reliability only found on genuine Stan’s NoTubes rims. - The perfect balance of strength and weight - 24% wider than the Arch EX for improved stability with larger tires - Same light weight as the Arch EX - Low-profile shape rolls faster, lasts longer, and helps stop tire pinch flats - 25% stiffer and stronger for improved handling - Lighter and more durable rim shape and alloy - Most trusted tubeless system for easy setup and low maintenance - WideRight optimized for Trail tires

- Deep section Urban/Fixie, Track racing rim for strength and aerodynamics - Non-machined sidewalls for added style points

Asym rims use an asymmetrical design to create a rim that evenly distributes tension, doesn’t require dishing, and makes for a faster wheel assembly. High end WT69 Alloy and an open cavity design keep Asym weights down while eyelets prolong longevity and prevent binding. Featuring a full TCS (tubeless compatible system) inner rim profile, Asym rims provide a lightweight, higher performance value-driven option that works exceptionally well with wheel building machines.

A trail rim that ticks all the boxes. SPANK Industries’ OOZY Trail 295 Rim is one of the most versatile trail rims on the market. Though built for trail, the OOZY Trail 295 rim is tough enough to handle more aggressive applications ranging from All Mountain to Enduro. Sporting a 24.5mm inner width, the OOZY Trail 295 rim is compatible with a broad range of tire sizes and profiles making it a true do it all rim solution. SPANK’s proprietary, lightweight and rigid Dynamal alloy gives the OOZY Trail 295 rim unparalleled strength at a weight competitive with carbon. As the first SPANK rim to feature SPANK’s revolutionary Bead Bite anti-burp technology, the OOZY Trail 295 rim set the standard for effectively preventing tire burps and restricting excessive tire rollover even at low tire pressures. Bead Bite, OohBah, Dynamal Alloy Material: MGR Dynamal Alloy Size (in.): 26" / 27.5" / 29" Weight (g): ±450 (26") / ±470 (27.5") /± 490 (29") Hole Count: 32H Inner / Outer Width: 24.5 / 29.5 Valve: F/V Presta Tubeless: Tubeless ready Finish: Polish anodized, decal logos ERD (mm++): 528 (26") / 555 (27.5") / 591 (29") ETRTO (mm): 559x24.5 (26") / 584x24.5 (27.5") / 622x24.5 (29") Discipline: Trail

WTB's proprietary 4D spoke drilling prevents binding and lateral loading of the spokes, while the spoke bed itself has been updated to provide a more compatible interface between the spoke and rim. Integration of the all-new Solid Strip on our TCS 2.0 rims delivers the easiest to mount and most reliable tubeless system we’ve ever made. Available in widths ranging from i23 to i45, because all bikes should benefit from lightweight rims. Features: - TCS 2.0 creates a more robust, easily installed and dependable tubeless system. - A recessed channel along the center of TCS 2.0 rims allows installation of the all-new Solid Strip, which prevents tubeless tape from sagging at the spoke holes and results in a smooth, consistent interface between the tire and rim. - 4D angled spoke drilling eliminates binding and lateral loading, and disperses tension more evenly over a greater area

WTB's proprietary 4D spoke drilling prevents binding and lateral loading of the spokes, while the spoke bed itself has been updated to provide a more compatible interface between the spoke and rim. Integration of the all-new Solid Strip on our TCS 2.0 rims delivers the easiest to mount and most reliable tubeless system we’ve ever made. Available in widths ranging from i21 to i45, because all bikes should benefit from lightweight rims. Features: - TCS 2.0 creates a more robust, easily installed and dependable tubeless system. - A recessed channel along the center of TCS 2.0 rims allows installation of the all-new Solid Strip, which prevents tubeless tape from sagging at the spoke holes and results in a smooth, consistent interface between the tire and rim. - 4D angled spoke drilling eliminates binding and lateral loading, and disperses tension more evenly over a greater area

- An ultra-wide, high performance alloy rim, weight optimized for Enduro, Trail and All Mountain use - Tubeless ready with anti-burp rim hooks to prevent the loss of pressure and keep tires firmly in place - 32 holes with an inner width of 35mm and outer width of 39.5mm provides ultra-wide support for Plus-Size and high volume tires - The corrugated rim center, a brand acclaimed technology, adds exceptional strength, making it more rigid and allowing the rim to be wider without adding material - Shotpeen finish to increase fatigue life and make it more durable - MGR Dynamal Alloy

Designed with input from Stan's Enduro World Series teams, the new Arch MK3 is ready to own every trail. WideRight optimized for maximum stability with 2.25-inch to 2.5-inch tires, Stan's expanded the internal width out to 26mm while keeping the rim incredibly light. The 27.5-inch Arch MK3 weighs only 425g. A new proprietary alloy and stronger, low-profile rim shape means the new Arch MK3 is built to last. Featuring Bead Socket Technology, the new Arch MK3 also offers the unmatched traction, control, and reliability only found on genuine Stan’s NoTubes rims. - The perfect balance of strength and weight - 24% wider than the Arch EX for improved stability with larger tires - Same light weight as the Arch EX - Low-profile shape rolls faster, lasts longer, and helps stop tire pinch flats - 25% stiffer and stronger for improved handling - Lighter and more durable rim shape and alloy - Most trusted tubeless system for easy setup and low maintenance - WideRight optimized for Trail tires

The new Flow MK3 is wider, stronger, and lighter. Flow’s legendary history on the World Cup DH circuit, combined with WideRight 29mm internal width, offers the perfect balance of tire stability for outstanding control at any speed. Genuine Bead Socket Technology rolls faster, corners harder, and withstands even bigger hits. Flow MK3 is born and bred for control at speed and perfect for technical trails and enduro racing thanks to increased lateral stiffness and durability. The new alloy is also even lighter, putting the new Flow MK3 in a class by itself for all-mountain performance. - 29mm internal width for tires up to 2.8" - Low-profile shape rolls faster, lasts longer, and helps stop tire pinch flats - Even lighter than the Flow EX - 25% stiffer and stronger for improved handling - More durable rim shape and alloy - Built on the proven success of our Flow EX on the World Cup DH circuit - Most trusted tubeless system for easy setup and low maintenance - WideRight optimized for Trail and All-mountain tires

Built for bashing, whether on a gravity shred sled or fully loaded bikepacking rig, WTB's KOM Tough rims are extruded from top-tier alloy to provide utmost durability at a reasonable weight. Their legendary I-Beam construction has evolved to further reinforce the rim with dual support beams that provide increased strength and stiffness for the world’s most aggressive riders. Proven on the toughest tracks of the Enduro World Series, depended on for daily trail rides, and trusted while bikepacking in remote regions of the world, KOM Tough rims are available in 25, 29, 35, 40 and 45mm widths to provide a burly rim for every usage and style of riding. Features: - TCS 2.0 creates a more robust, easily installed and dependable tubeless system. - A recessed channel along the center of TCS 2.0 rims allows installation of the all-new Solid Strip, which prevents tubeless tape from sagging at the spoke holes and results in a smooth, consistent interface between the tire and rim. - 4D angled spoke drilling eliminates binding and lateral loading, and disperses tension more evenly over a greater area.
