Details
The Rebel Yell of the middle child. Fed a steady diet of super-tech climbs, the SB130 was built to crush the biggest terrain. No trail is "too" anything. Point it up or down. Enter a last-minute enduro just for the fun of it. We like to say no one bike can rule it all. But the SB130? It's one bike that rules.
- At the heart of the SB130 suspension design is the Yeti patented Switch Infinity suspension system.
- The SB130 is built to tackle any type of terrain. From buffed out singletrack, to rugged EWS racecourses, it can hold its own on a huck.
- The SB130 has progressive trail-inspired geometry. Yeti took what they learned from the SB5 and their Factory team riders and incorporated it here.
- A patent-pending wishbone shock extender was developed to change the leverage ratio and shock clearance.
- No more gunk on your water bottle mouthpiece, as the mount is now inside the front triangle.
- An integrated headset allows for a lower overall stack height and cleaner carbon layup.
- Internally tunneled routing allows for clean lines, ease of maintenance, and less shifting of housing during suspension movement.
- Switch Infinity utilizes a patented translating pivot that switches direction as the bike moves through its travel.
- Yeti linear system built by FOX is able to achieve infinite tunability and durability, which cannot be matched by traditional link designs.
- Decoupling of the chain forces allows the suspension to work more efficiently to absorb impacts.
- The ability to manipulate the leverage ratio without affecting the anti-squat characteristics is unique to Switch Infinity suspension.
Build Highlights
- TURQ Series carbon fiber frame
- FOX Factory Fit 4 36 fork
- FOX Factory Float rear shock
- SRAM X01 Eagle drivetrain
- SRAM G2 RSC brakes
- DT Swiss M1700 wheels*
- FOX Transfer dropper post
* Bike may ship with DT SWISS XM481 30MM wheels
PEDALS SOLD SEPARATELY
TURQ SERIES FRAME:
TURQ Series bikes are made with the highest quality carbon fiber available and offer the perfect balance of stiffness and compliance. The result is a bike that feels smooth, solid and aggressive. Every bike is tested by the best racers in the world, including EWS World Champion Richie Rude, their in-house testing team and Yeti ambassadors around the world.
A dropper seatpost allows you to quickly lower and raise your seat to give you an ideal riding position. Dropping your seat creates a lower center of gravity for better control and maneuverability on steep descents, while raising it puts you at normal riding height for efficient pedaling.
Construction can include either hydraulic- or cable-actuated systems and the post’s travel can either be infinitely adjustable or stopped at set intervals, depending on the model.
Dropper seatposts come in standard lengths and diameters and vary by the amount of travel.
Specs
Frame | TURQ Series carbon fiber frame, Switch Infinity suspension technology, press-fit BB92, internally tunneled cable routing, 148mm x 12mm BOOST dropouts, sealed enduro max pivot bearings, integrated derailleur hanger, and axle. |
---|---|
Fork | FOX FACTORY 36 FIT 4/150mm |
Headset | CANE CREEK 40 INTEGRATED |
Rear Shock | FOX FACTORY FLOAT X |
Axles |
Front: 15 x 110mm Boost thru-axle Rear: 12 x 148mm Boost thru-axle |
Rims/Wheels | DT SWISS XM1700 30mm ( *Orders may ship with DT SWISS XM481 30mm wheels) |
Hubs | DT SWISS XM1700 |
Spokes | DT SWISS XM1700 |
Tires | F: MAXXIS MINION DHF 2.5 EXO, R: MAXXIS AGGRESSOR 2.3 EXO |
Crankset | SRAM X1 EAGLE 170mm |
Chainrings | 30T |
Bottom Bracket | SRAM DUB BB92 |
Chain | SRAM GX EAGLE |
Rear Derailleur | SRAM X01 EAGLE |
Cassette/Rear Cogs | SRAM X01 EAGLE 1295 10-52 |
Shifters | SRAM X01 EAGLE |
Handlebars | YETI CARBON 35x780mm |
Tape/Grips | ODI ELITE PRO |
Stem | RACE FACE AEFFECT R 35x50mm |
Brake Levers | SRAM G2 RSC |
Brakes | SRAM G2 RSC w/SRAM CENTERLINE 200mm (F) & 180mm (R) ROTORS |
Saddle | WTB SILVERADO CUSTOM |
Seat Post | FOX TRANSFER 31.6mm / SM: 125mm, MD: 150mm, LG-XL: 175mm |
* Subject to change without notice.
Videos
Yeti Cycles: SB130
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Turquoise / T2 Build Kit / Small | |||
Turquoise / T2 Build Kit / Medium | 605832520001 | B22130TMDPTUFXT026500 | SB1227328752 |
Turquoise / T2 Build Kit / Large | |||
Turquoise / T2 Build Kit / X-Large | |||
Raw Carbon / T2 Build Kit / Small | |||
Raw Carbon / T2 Build Kit / Medium | |||
Raw Carbon / T2 Build Kit / Large | |||
Raw Carbon / T2 Build Kit / X-Large | |||
Rhino / T2 Build Kit / Small | |||
Rhino / T2 Build Kit / Medium | |||
Rhino / T2 Build Kit / Large | |||
Rhino / T2 Build Kit / X-Large | |||
Watermelon / T2 Build Kit / Small | |||
Watermelon / T2 Build Kit / Medium | |||
Watermelon / T2 Build Kit / Large | |||
Watermelon / T2 Build Kit / X-Large |
