Trek Custom Fuel EX 8 XT Gen 6 - 2023

Trek Custom Fuel EX 8 XT Gen 6
$3,949.93
$5,000.00
Color: Matte Pennyflake
Size: X-Large
Wheel Size: 29-inch
Please select options Unavailable
This item is not permitted to be shipped. However, it can be purchased online for in store pick up or our delivery service within Toronto.

Details

• This bike is used and show minimal signs of wear and tear with some minor scratches and scuffs. Mechanically it's in excellent working order having been recently tuned by our expert service department and includes a standard Trek frame warranty.

• This bike features a mix of new and used components (full details in the specs) including brand new Bontrager Line Comp wheels and new Shimano rotors and rear brake pads

• This bike features several upgrades from the stock build including a OneUp V2 dropper post and Shimano SLX cranks (came stock with Deore)

• The rear shock had a full rebuild at the end of the 2024 season The fork lowers were serviced with new SKS seals installed at the same time

• Some custom aesthetic features include, Silver Fox fork decals and dials and a silver seat post collar.

• As this is a used bike, it can be shipped within the country at an additional cost. Contact info@sweetpetes.com for more information


The Trek Fuel EX 8 is a dialed trail bike for riders who chase down rowdy descents and want a bike that's happy to pedal back to the top and do it again. It has a stout alloy frame and an upgraded Shimano XT drivetrain for smooth precise shifting. The 150mm Fox Rhythm fork makes easy work of rocks and roots while the Fox Float X shock keeps you in control. New in frame storage and adjustable geometry give you all the perks that come with the carbon model, but without the lofty price tag.

You want a full suspension trail bike that prioritizes suspension and shifting performance over a more expensive carbon frame.

A light and stiff alloy frame with 150mm FOX Rhythm fork with Float EVOL air spring and GRIP damper for small bump compliance, plus a FOX Performance Float X rear shock. A Shimano XT 12-speed drivetrain for snappy shifting, and tubeless-ready Bontrager wheels. Plus, new adjustable geometry that lets you take control of your setup.

For the rider who doesn't want to be limited on the trail, Fuel EX 8 is ready to handle everything. Its progressive trail geometry is built to keep you charging, and upgraded components are they cherry on top.

• This bike is built to take on the singletrack, with modern geometry that's evolved to handle the rough and rowdy
• You'll get upgraded components where it matters most, with 12-speed XT shifting, and a rock-gobbling FOX Rhythm 36 fork
• With the adjustable angle headset (angled cups sold separately) and Mino Link, you can choose from six different geometry configurations
• Trek expanded their size range to ensure a better fit for all riders, and use the best-fitting wheels for each frame size: X-Small frames get 27.5" wheels, Small frames get to choose between 27.5" or 29", and sizes Medium and up get 29" wheels

Geometry Chart:
FRAME SIZEX-SmallSmall 27.5Small 29MediumMedium/LargeLargeX-LargeXX-Large
WHEEL SIZE (in) 27.5 27.5 29 29 29 29 29 29
FRAME REACH (mm) 400.2 430.2 425 450 470 485 515 545
EFFECTIVE TOP TUBE (mm) 516.2 550.5 553.8 584.1 607.4 626.9 661.8 696.6
SEAT TUBE (mm) 360 380 380 410 420 435 470 500
SEAT TUBE ANGLE (°) 70.8 70.8 70.8 70.8 70.8 70.8 70.8 70.8
EFFECTIVE SEAT TUBE ANGLE (°) 78.6 78.2 78.6 78.2 77.5 77.2 76.6 76
FRAME STACK (mm) 574.1 574.1 612.3 616.8 616.8 621.3 634.9 648.4
HEAD TUBE LENGTH (mm) 95 95 95 100 100 105 120 135
HEAD TUBE ANGLE (°) 64.5 64.5 64.5 64.5 64.5 64.5 64.5 64.5
FORK AXLE-TO-CROWN (mm) 533 533 561 561 561 561 561 561
BOTTOM BRACKET HEIGHT (mm) 332 332 335 335 335 335 335 335
BOTTOM BRACKET DROP (mm) 25 25 38 38 38 38 38 38
CHAINSTAY LENGTH (mm) 435 435 435 435 440 440 445 450
WHEELBASE (mm) 1144.8 1174.8 1185.9 1213 1233.1 1250.2 1286.7 1323.2
STANDOVER (mm) 716.8 723.8 736.8 736.8 741.8 747.8 766.8 773.8
OFFSET (mm) 44 44 44 44 44 44 44 44
TRAIL (mm) 121.6 121.6 129.2 129.2 129.2 129.3 129.3 129.3
Sizes:
SizeRider HeightInseam
X-Small

137 - 155 cm

4'6" - 5'1"

64 - 73 cm

25" - 29"

Small

153 - 167 cm

5'0" - 5'6"

72 - 79 cm

28" - 31"

Medium

161 - 172 cm

5'3" - 5'8"

76 - 81 cm

30" - 32"

Medium/Large

166 - 179 cm

5'5" - 5'10"

77 - 84 cm

30" - 33"

Large

177 - 188 cm

5'10" - 6'2"

83 - 88 cm

33" - 35"

X-Large

186 - 196 cm

6'1" - 6'5"

87 - 92 cm

34" - 36"

XX-Large

195 - 203 cm

6'5" - 6'8"

92 - 95 cm

36" - 37"

Specs

Frame Alpha Platinum Aluminum, internal storage, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, guided internal routing, magnesium rocker link, 34.9mm seat tube, ISCG 05, 55mm chainline, BSA 73, downtube guard, shuttle guard, ABP, UDH, Boost148, 140mm travel
Fork Fox Rhythm 36, Float EVOL air spring, GRIP damper, tapered steerer, 44mm offset, Boost110, 15mm Kabolt axle, 150mm travel
Rear Shock Fox Performance Float X, 2-position damper, 185mm x 55mm
Wheels NEW Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost, 15mm thru axle<
Rims Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle
Hubs Front: Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15mm thru axle
Rear: Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle
Tires Bontrager XR5 Team Issue, Tubeless Ready, aramid bead, 120 tpi, 29x2.50''
Bottom Bracket Shimano BB-MT501 BSA
Crankset Shimano SLX FC-M7120 175mm
Chainrings 30T
Shifters Shimano XT M8100, 12 speed
Rear Derailleur Shimano XT M8100 12 spd, long cage
Cassette/Freewheel Shimano XT M8100, 10-51, 12 spd
Chain Shimano SLX M7100, 12 spd
Brakes Shimano 4-piston hydraulic disc, M6100 lever, M6120 caliper
Rotors NEW Shimano RT66, 6-bolt, (F) 203 mm, (R)180mm
Brake Levers Shimano M6120 4-piston hydraulic disc
Handlebars Bontrager Line, alloy, 35mm, 27.5mm rise, 780mm width
Tape/Grips Bontrager XR Trail Elite, nylon lock-on
Stem Bontrager Elite, 35mm, 0 degree, 45mm length
Headset Integrated cartridge bearing, 1-1/8'' top, 1.5'' bottom, angle adjust cup compatible
Seatpost OneUp V2 Dropper Post 180mm travel, internal routing 34.9mm
Saddle Bontrager Arvada, hollow chromoly rails, 138mm width
Pedals Sold Separately
Accessories & Extras Bontrager BITS Internal Frame Storage Bag, Bontrager Side Load Bottle Cage

* Subject to change without notice.

Part Numbers

Option MPN Store SKU
Matte Pennyflake / X-Large / 29-inch C-5272040 FUE28879441E
