White-hot Canadian speed!
The everyday crusher of all trails. This Troy is their most advanced aluminum frame yet. But don’t let its handsmooth welds, streamlined profile and internal routing fool you. More than ever, Troy is built to shred. It has an updated geometry with size-specific chainstay lengths and comes stock with mixed wheels. It has more travel (150mm), so you’ll be looking for challenges instead of excuses. And its new ‘shed’ storage compartment in the downtube lets you pack all you need, without the need for a pack. Devinci's quiver killer has a new set of instincts, and they’re backed by a lifetime warranty. Take one for a ride and see how far you can push it. You might never come back.
MIXED WHEELS
The Troy comes stock with mixed wheels. Get all the snappy handling of 27.5" with the added traction, rollover and momentum of a 29" wheel up front. Still prefer full 29? The Geo-Saver mullet flip chip located at the lower mount of the shock lets you rock a 29’’ rear wheel without sacrificing the bike’s intended geometry.
MORE TRAVEL MORE POTENTIAL
Although we bumped up the travel to 150mm – 160mm for this new generation of the Troy, it still remains the ‘quiver-killer’ in Devinci’s lineup. One bike to do it all. From greens to blacks, flowy to techy, jumps to slabs, we believe the Troy will elevate your ride, no matter where you take it.
ROCK SHOX ULTIMATE SERIES
Offering maximum adjustability and featuring the latest innovations in damper technology, RockShox’s Ultimate series represents the pinnacle of the suspension manufacturer’s lineup. The Troy GX AXS is equipped with the Lyrik Ultimate fork, which includes the 3.1 Charger damper, ButterCups, and the DebonAir+ air spring. At the rear, RockShox’s Super Deluxe Ultimate with Linear XL Air Can takes care of rear shock duties, delivering incredible traction, tunability, and control.
FRAME TECH SPECS:
• Rear travel: 150 mm
• Front travel: 160 mm
• Rear tire clearance: 27,5'' x 2.6” / 29'' x 2.5''
• Rear hub spacing: 12 x 148 Boost
• Max & min chainring clearance Max. 34T | Min. 28T
• Chainline: 55 mm
• Derailleur hanger: UDH™
• Caliper mount: 200 mm Post Mount
• Seat tube diameter: 31.6 mm ID / 34.9 mm OD
• Seatpost max insertion: S ? 240 mm / M ? 280 mm / L ? 305 mm / XL ? 330 mm
• Headset: Top ZS44 | Bottom ZS56
• Cable routing: Internal
• Rear shock dimension: Trunnion | 185 x 55 mm
• Rear shock hardware: Top: NA | Bottom: 40 x 10 mm
• Linkage bearing type: Enduro™ double-lip sealed
• Fork dimensions (Axle-to-Crown measurement/Offset): 571 mm / 44 mm
• Chain guide mount: ISCG 05 – 3-Bolt
• Frame material: Aluminum 6061-T6 | Optimum G04
Specs
Frame | Aluminum Optimum G04 150mm |
---|---|
Fork | Rockshox Lyrik Ultimate DB | 29 | 160 | 110x15 | 44OS |Black |
Headset | FSA Orbit | 1.5 | Zero Stack |
Rear Shock | RockShox SuperDeluxe Ultimate 185x55T |
Rims/Wheels | (F) RaceFace ARC30 29 | 30mm inner | TR (R) RaceFace ARC30 27.5 | 30mm inner | TR |
Hubs | (F) RaceFace Vault | 6bolts | TA 15x110mm (R) RaceFace Vault | Boost148x12 | XD | 6bolts |
Spokes | Sapim Stainless 14G w/Nylok |
Tires | (F) Maxxis Minion DHF | 29x2.5WT | 3C | DD | TR | MaxxTerra (R) Maxxis Minion DHR II | 27.5x2.5WT | 3C | DD | TR | MaxxTerra |
Crankset | SRAM GX Eagle AXS | T-Type | 1Guard | Boost 148 |
Chainwheel | 32T |
Bottom Bracket | SRAM DUB 73mm Threaded |
Chain | SRAM GX | T-Type | 12s |
Rear Derailleur | SRAM GX Eagle AXS | T-Type | 12s |
Rear Cogs | SRAM XS1275 | T-TYPE | 12s | 10-52T |
Shifters | SRAM AXS POD | 12s |
Handlebars | RaceFace ERA 35 | B:35mm | R:40mm | W:800mm |
Tape/Grips | Devinci Performance | w/lock-on |
Stem | RaceFace Turbine R35 | B:35mm | L:40mm | 0° |
Brake Levers | SRAM Code Silver |
Brakes | SRAM Code Silver |
Pedals | NA |
Saddle | SDG BELAIR 3.0 |
Seat Post | SDG Tellis 31.6mm |
Color(s) | Matcha |
Sizes | S. M, L, XL |
Weight | (M) 16.05 kg / 35.38 lb |
* Subject to change without notice.
